Allen-Bradley 1762-IQ8OW6 MicroLogix Combination I/O Module

Allen-Bradley 1762-IQ8OW6 MicroLogix Combination I/O Module

The Allen-Bradley 1762-IQ8OW6 delivers versatile control for your MicroLogix system. This compact module combines digital inputs and relay outputs in one unit. It provides excellent flexibility for various industrial automation applications.

Technical Specifications

• Brand: Allen-Bradley
• Model: 1762-IQ8OW6
• Series: MicroLogix
• Module Type: Combination I/O
• Input Channels: 8 (sink/source compatible)
• Input Voltage: 10-30V DC @ 30°C (86°F)
• Output Channels: 6 Form A relay outputs
• Output Rating: 2.5A @ 240VAC, 2.0A @ 24VDC
• Output Voltage Range: 5-265V AC, 5-125V DC
• Response Time: 8ms input, 10ms output
• Power Consumption: 110mA @ 5V DC, 80mA @ 24V DC
• Heat Dissipation: 5.0W @ 30V DC
• Operating Temperature: 0-65°C (32-149°F)
• Dimensions: 90 x 40.4 x 87 mm (3.54 x 1.59 x 3.43 in)
• Weight: 280g (0.62 lb)

Packaging & Shipping

• Package Includes:
  • One 1762-IQ8OW6 Combination I/O Module
  • Installation documentation
• International shipping via FedEx, UPS, and DHL
• Express delivery options available

Frequently Asked Questions

• Which MicroLogix controllers support this module?
  The 1762-IQ8OW6 works with MicroLogix 1100, 1200, and 1400 controllers.
• Can I mix AC and DC loads on the relay outputs?
  Yes, each relay output handles both AC and DC loads within specified ratings.
• What is the maximum distance from the power supply?
  This module must be within six modules of the main power supply.
• Are the inputs compatible with both sinking and sourcing devices?
  Yes, the input channels work with both sinking and sourcing field devices.
• What is the relay life expectancy?
  Relay life depends on load type and switching frequency, typically 100,000+ operations.
