Allen-Bradley 1756-OB16IEFK Module – 16-Channel

Allen-Bradley 1756-OB16IEFK Module – High-Density 16-Channel DC Output

Precision DC Load Control

The 1756-OB16IEFK from Allen-Bradley provides 16-channel DC output for industrial automation. This ControlLogix module delivers 2A per point (8A total) with 10-30V DC range – ideal for relays, valves and indicators. Download complete specifications for technical details.

Technical Specifications

• Brand: Allen-Bradley/Rockwell Automation
• Model: 1756-OB16IEFK
• Outputs: 16 isolated channels
• Voltage: 10-30V DC
• Current: 2A/point, 8A/module @30°C
• Terminal Blocks: 1756-TBCH/TBS6H
• Power: 350mA @5V, 3mA @24V
• Isolation: 50V continuous
• Weight: Lightweight design
• Response Time: <5ms typical

Shipping & Support

• Fast worldwide delivery via FedEx, UPS, DHL
• 12-month warranty

Technical Questions

• Q: Can 1756-OB16IEFK handle inductive loads?
  A: Yes, with proper suppression.
• Q: What wire size fits the terminals?
  A: Accepts 22-14 AWG.
• Q: Is surge protection included?
  A> External protection recommended.
• Q: Can I mix voltage levels?
  A: No, single voltage only.
• Q: What’s the operating temperature?
  A: 0-60°C (32-140°F).
