Allen-Bradley 1756-OA16 ControlLogix Output Module

Allen-Bradley 1756-OA16 – Robust AC Output Module

Technical Specifications

• Brand: Allen-Bradley/Rockwell
• Model: 1756-OA16
• Series: ControlLogix
• Type: AC Output Module
• Voltage: 74-265V AC (47-63Hz)
• Current: 0.5A/point, 4A/module
• Terminal Blocks: 1756-TBNH/TBSH compatible
• Power Dissipation: 6.5W max
• Operating Temp: 0-60°C (32-140°F)
• Isolation: 50V continuous
• Backplane Power: 400mA @5V DC

Why Choose This Module?

• Proven Reliability: Industrial-grade construction
• Easy Integration: Works with all ControlLogix processors
• Safety Features: Built-in fuse protection
• Fast Shipping: FedEx/UPS/DHL available
• Full Warranty: 12-month protection

Download Complete Documentation

Get detailed specifications for installation and technical data.

Expert FAQs

• Q: What chassis are compatible?
  A: All 1756-A series (A4 to A17)
• Q: Can it drive contactors directly?
  A: Yes, up to 0.5A – use interposing relays for higher loads
• Q: Are terminal blocks included?
  A: No, requires 1756-TBNH or 1756-TBSH (sold separately)
• Q: How are faults indicated?
  A: Via FuseBlown and FieldPwrLoss status tags
• Q: What’s the switching speed?
  A: 9.3ms (ON), 11ms (OFF) at rated load

Order Today – Reliable AC Control

Get your Allen-Bradley 1756-OA16 module now – industrial performance you can trust!
