Allen Bradley 1756-IB16 Input Module | 16-Ch DC | ControlLogix

Allen Bradley 1756-IB16 ControlLogix Input Module – Fast Response Guardian

Lightning-Fast Sensing

• 1ms response time (ON transition)
• Configurable filtering: 0-18ms selectable delay
• 10-31.2VDC operating range (24V nominal)
• Low current detection: 2mA @10V

Industrial Tough Design

• Operating temp: 0-60°C (32-140°F)
• Vibration resistance: 5g @ 10-500Hz
• Shock survival: 30g operational impact
• Humidity range: 5-95% non-condensing

Smart Features

• Change-of-State detection for instant alerts
• Hot-swappable with 1756-TBCH/TBS6H terminals
• Dual-group isolation (8 points per group)
• LED status per channel: Green=active

Performance Data

• Max OFF-state current: 1.5mA
• Backplane power: 0.56W
• Update speed: 200µs-750ms
• Inrush protection: 250mA peak

Warranty & Shipping

• 12-month performance warranty
• Global delivery: FedEx | UPS | DHL
• Tested before shipment

Technical Documentation

Download Installation Guide ↗
Complete wiring diagrams and configuration details

Expert FAQs

• Q: Minimum voltage for signal detection?
  A: 10VDC guaranteed activation
• Q: Can I use with 12V sensors?
  A: Yes – operates down to 10VDC
• Q: Replace without system shutdown?
  A: Yes – hot-swappable design
• Q: Maximum wire distance?
  A: 100m (328ft) with 24AWG cable
• Q: Status LED meaning when red?
  A: Indicates channel fault or misconfiguration

Package Contents

• 1756-IB16 input module
• Installation manual
