Allen-Bradley 1746-IV16 SLC 500 Input Module – 16 Point Sourcing

Allen-Bradley 1746-IV16 Sourcing Input Module – Reliable 24V DC Control

The Allen-Bradley 1746-IV16 is a discrete input module for SLC 500 systems. It has 16 sourcing input channels. It works with devices like switches and sensors. This module is perfect for industrial automation.

Technical Specifications

• Brand: Allen-Bradley
• Model: 1746-IV16
• Series: SLC 500
• Type: 24V DC Sourcing Input Module
• Input Voltage: 10-30V DC
• Nominal Current: 8 mA at 24V DC
• Off-State Current: 1 mA max
• Power Dissipation: 3.6 Watts
• On Delay: 0.3 ms
• Off Delay: 0.5 ms
• Backplane Current: 85 mA at 5V DC
• Operating Temperature: 0 to 60°C (32 to 140°F)

Frequently Asked Questions

• What does sourcing input mean?
  The module provides voltage to the field device.
• How many devices can I connect?
  You can connect up to 16 devices.
• What is the operating voltage range?
  It works from 10 to 30V DC.
• Are the LEDs useful for troubleshooting?
  Yes, they show each input’s status.
• Is this module compatible with my SLC 500 system?
  Yes, it works with all SLC 500 CPUs.
