Allen-Bradley 1746-FIO4V SLC 500 Analog Combo Module

Product Overview

Technical Specifications

Brand: Allen-Bradley / Rockwell Automation

Model: 1746-FIO4V

Series: SLC 500 Analog Combination Module

• Input Channels: 2
• Input Types: Selectable per channel (Voltage or Current)
• Voltage Input Range: 0 to +10 VDC
• Current Input Range: 0 to 20 mA (0 to 30 mA max)
• Output Channels: 2 (Voltage)
• Voltage Output Range: -10 to +10 VDC
• Input Resolution: 12 bits
• Output Resolution: 14 bits
• Update Time: 512 µs
• Bandwidth: 7 kHz
• Step Response: 100 ms (in), 2.5 ms (out)
• Backplane Current: 55 mA @ 5V; 150 mA @ 24V
• Isolation: 500V DC
• Operating Temperature: 0 to 60° C
• Relative Humidity: 5% to 95% (non-condensing)

Installation Guide

Install the module in a SLC 500 chassis. Keep it away from noise sources.

• Place module away from AC power lines
• Avoid high-voltage DC sources
• Do not install near the rack power supply
• Ensure proper ventilation to manage temperature
• Use 14 AWG wire for connections

Package Includes:

• One 1746-FIO4V module

Warranty: 12 months

Shipping: FedEx, UPS, DHL available
