Allen-Bradley 1734-IE2V Analog Input Module

Allen-Bradley 1734-IE2V Analog Input Module

The Allen-Bradley 1734-IE2V is a precise analog input module. It works with POINT I/O systems from Rockwell Automation. This module offers two voltage input channels with excellent accuracy.

Technical Specifications

• Brand: Allen-Bradley
• Model: 1734-IE2V
• Series: POINT I/O 1734
• Module Type: Analog Voltage Input
• Number of Inputs: 2 single-ended channels
• Input Range: 0-10V or ±10V configurable
• Resolution: 16-bit signed integer
• Accuracy: 0.1% full scale at 25°C (77°F)
• Conversion Type: Delta Sigma
• Power Supply: 12-24V DC
• Power Dissipation: 0.75W at 28.8V DC
• Operating Temperature: -20 to 55°C (-4 to 131°F)
• Data Format: 6 bytes (channel data + status)

Package Contents

• One 1734-IE2V analog input module
• Terminal block connector
• Mounting hardware
• Quick start guide

Frequently Asked Questions

• What voltage ranges does it support?
  It supports 0-10V and ±10V configurable ranges.
• What is the resolution of this module?
  It provides 16-bit signed integer resolution.
• Can I adjust the input sampling rate?
  Yes, it offers adjustable input rates for different signals.
• What types of alarms does it support?
  It features configurable Low, Low-Low, High, High-High alarms.
• Is this module isolated?
  No, it features non-isolated single-ended inputs.
