Allen-Bradley 1734-IA2 Digital AC Input Module

The 1734-IA2 is a compact 120V AC input module from Allen-Bradley’s POINT I/O series. This module provides two isolated input channels for industrial automation applications. It offers reliable performance in a space-saving design for control systems.

Technical Specifications

• Brand: Allen-Bradley
• Model: 1734-IA2
• Input Channels: 2 isolated channels
• Input Voltage: 120V AC (85-132V AC range)
• Frequency: 47-63 Hz
• Input Impedance: 10.6 kΩ nominal
• Isolation Voltage: 240V AC continuous
• Dielectric Test: 3250V DC for 60 seconds
• Power Consumption: 75 mA at 5V DC
• Power Dissipation: 0.1W maximum
• Weight: 30.9 grams (1.09 ounces)
• Dimensions: 56.0 x 12.0 x 75.5 mm

Package Contents & Delivery

• One 1734-IA2 AC input module
• Installation and specification guide
• Fast worldwide shipping via FedEx, UPS, DHL

Frequently Asked Questions

• How many input channels does this module have?
  It provides two completely separate 120V AC input channels.
• What voltage range can it accept?
  It works with 85-132V AC at 47-63 Hz frequency.
• What networks support this module?
  It works with ControlNet, DeviceNet, and EtherNet/IP systems.
• How can I monitor input status?
  Each channel has a dedicated status indicator light.
• Can I install this module in any position?
  Yes, it supports both horizontal and vertical mounting.
