Allen-Bradley 1734-ADNX DeviceNet Adapter – POINT I/O Module

Allen-Bradley 1734-ADNX DeviceNet Adapter Module

The Allen-Bradley 1734-ADNX connects POINT I/O modules to DeviceNet networks. It works as both a master and slave device. This module makes industrial communication simple and reliable.

Technical Specifications

• Brand: Allen-Bradley
• Model: 1734-ADNX
• Input Voltage: 24V DC
• Field Side Power: 400 mA
• Inrush Current: 6 A
• POINTBus Current: 1000 mA
• Power Consumption: 8.1 W
• Power Dissipation: 2.8 W at 28.8V
• Operating Temperature: -20°C to 55°C
• Storage Temperature: -40°C to 85°C
• Communication: DeviceNet protocol
• Isolation Voltage: 500V DC

Installation Guide

• Mount at the left side of your 1734 system
• Use a 24V DC SELV or PELV power supply
• Connect to DeviceNet network using standard cables
• Status LEDs help during setup and troubleshooting

Package Includes

• One 1734-ADNX DeviceNet Adapter module
• Required mounting hardware
• Quick start guide

Warranty

• 12-month warranty
• Contact us for warranty claims and support

Frequently Asked Questions

• What networks does the 1734-ADNX support?
  It works with DeviceNet networks and POINT I/O modules.
• Can I replace modules without reconfiguring?
  Yes, the Auto Catalog Replace feature helps with this.
• What power supply do I need?
  You need a 24V DC SELV or PELV power supply.
• How many status indicators does it have?
  It has three red/green status lights and two green power indicators.
• Where does this module install in a system?
  It mounts on the left side of your 1734 POINT I/O rack.
