Product details
AI-TEK Speed Sensor Overview
70085-3030-212 gives steady speed signals in many harsh places. Easy to mount and built to last. Written by Powergear X Automation. Contact us: sales@powergearx.com or +86 18030005825.
Main Specs
- Part Number: 70085-3030-212
- Thread Size: 5/8-18
- Output Guarantee Voltage: 13.4 V (P-P)
- Termination: Cable
- Thread Length: 2.75 in
- Sensor Length: 4 in
- Temp Range: -65°C to 95°C
- Cable Length: 10 m
- Conduit Thread: 1/2 NPT
- Agency Approval: None
Extra Technical Data
- Coil DC Resistance: 1200–1600 Ω typical
- Inductance Range: 0.35–0.50 H
- Speed Range: 0–22 kHz
- Rise Time: 10–20 μs
- Housing Material: Stainless steel
- Shock Limit: 100 g
- Vibration Level: 20 g RMS
- Output Type: Passive magnetic pickup
Key Benefits
- Long 10 m cable for remote sensing
- Works well in cold and hot areas
- Strong body for tough sites
- Good signal at slow or fast speed
- Simple thread mount for engines and drives
- Low noise over long cable runs
Warranty & Shipping
- 12-month warranty
- Ships by FedEx, UPS, DHL
- 100% original and fully tested
Professional FAQ
- Q1: What gap works best with this sensor?
- A: Most users set 0.020–0.050″. Adjust until the signal is clear and stable.
- Q2: Can this sensor handle long cable runs?
- A: Yes. For very long runs, shielded cable improves noise protection.
- Q3: What signs show the sensor is too far from the gear?
- A: Weak waveform, low voltage peaks, or missing pulses at low speed.
- Q4: Is this model suited for engine retrofits?
- A: Many customers use it on engines, turbines, and gearboxes with good results.
- Q5: How do I prevent thread damage during installation?
- A: Apply light torque and avoid cross-threading. Hand start before using tools.
