Introducing the AI-TEK Magnetic Speed Sensor
Powergear X Automation presents the AI-TEK 70085-1010-004 magnetic speed sensor. This robust sensor delivers precise rotational speed monitoring for industrial machinery. It operates effectively in extreme temperature conditions from -73°C to +107°C. The device ensures reliable performance with a guaranteed peak-to-peak output voltage.
Key Technical Specifications
- Brand: AI-TEK
- Model: 70085-1010-004
- Output Voltage (Guaranteed): 4.3 V (P-P)
- Standard Output Voltage: 43 V (P-P)
- DC Resistance: 130 ohms maximum
- Typical Inductance: 32-46 mH (reference)
- Operating Temperature: -73°C to +107°C
- Output Polarity: Red lead positive
Physical Dimensions & Construction
- Thread Size: 5/8-18 UNF
- Thread Length: 1.125 inches
- Total Sensor Length: 2.125 inches
- Lead Wire Length: 10 feet (3.05 meters)
- Maximum Net Weight: 16 ounces
- Termination: Wire leads
Installation & Integration
- Install the sensor using its standard 5/8-18 UNF thread.
- Ensure a proper mounting clearance of 1.125 inches.
- Connect the wires noting the red lead is positive.
- The long 10-foot cable allows for flexible placement.
Packaging & Shipping
- Each unit comes individually packaged.
- We ship globally via FedEx, UPS, and DHL.
- Track your order directly with the courier.
Frequently Asked Questions
- What is the minimum voltage this sensor produces?
- The AI-TEK 70085-1010-004 guarantees a 4.3 V P-P signal.
- Can it function in very cold environments?
- Yes, it operates reliably at temperatures as low as -73°C.
- What is the best way to verify sensor operation?
- Check for AC voltage output on the red wire during shaft rotation.
- Is this sensor suitable for high-speed applications?
- Its frequency response handles most industrial rotational speeds.
For specific technical requirements or volume pricing, contact our team. Email us at sales@powergearx.com or message on WhatsApp at +86 18030005825.
