Product details
Overview
The Bently Nevada 991-06-70-02-05 vibration transmitter is engineered for hazardous and marine environments. With ATEX Zone 0/2 and ABS certifications, it ensures safe operation in explosive atmospheres and offshore applications. Its bulkhead screw mounting provides secure installation in high-vibration machinery.
Model Code Breakdown ( 991-06-70-02-05)
| -06 | Range | ±0.6 mm (±24 mils) |
| -70 | Cable | 7 m (23 ft) system length |
| -02 | Mount | Bulkhead screws |
| -05 | Certifications | CSA/ATEX/ABS |
Key Specifications
- ⚡ Hazard Ratings: ATEX Zone 0 (continuous) & Zone 2
- ⚡ Marine Approval: ABS Type 1 for shipboard use
- ⚡ Fault Response: <3.6 mA in 100 µs (0.0001 sec)
Technical Data
| Electrical | 4–20 mA (2-wire) |
| Power | +12–35 Vdc |
| Accuracy | ±1.5% full scale |
| Temp Range | -35°C to +85°C |
Environmental Resilience
- ✅ Salt spray tested per ASTM B117 (500 hrs)
- ✅ IP68 waterproof/dustproof rating
- ✅ 20 g vibration resistance (IEC 60068-2-6)
Certifications
- ▸ ATEX II 1/2G Ex ia IIC T4 Ga
- ▸ ABS 2-18.1.1 Marine Machinery
- ▸ CSA C22.2 No. 0-10
For more detailed information:991 Thrust Transmitter Datasheet
