Meggitt Vibro-Meter Proximity Measuring System
The 913-402-000-012/A2-E095-F0-G000 provides precise proximity measurement in explosive environments. This Ex i certified system features a 9.5 meter cable for flexible installation. The 913-402-000-012/A2-E095-F0-G000 ensures reliable operation in demanding industrial conditions.
Product Configuration Breakdown
- Base Model: 913-402-000-012 Proximity System
- Environment Rating: A2 – Explosive Atmosphere Ex i
- Cable Length: E095 – 9.5 meters ±950 mm
- Protection: F0 – No Additional Protection
- Flexible Hose: G000 – No Hose Included
Technical Specifications
- Cable Length: 9.5 meters with ±950 mm tolerance
- Operating Temperature: -40°C to +180°C
- Short-Term Survival: Up to +220°C maximum
- Weight: 0.22 kilograms total system weight
- Vibration Resistance: 5 g peak from 10-500 Hz
- Shock Resistance: 15 g peak, 11 ms duration
- IP Rating: IP68 for transducer head
- Cable Type: FEP covered 70 Ω coaxial
- Cable Diameter: 3.6 mm standard size
- Connector Type: Self-locking miniature coaxial
Key Features & Benefits
- Ex i certification for explosive environments
- 9.5 meter cable provides installation flexibility
- IP68 rating ensures complete dust and water protection
- High-temperature operation up to 180°C continuous
- Stainless steel AISI 316L construction for corrosion resistance
- Torlon probe tip for excellent wear resistance
- Self-locking connectors prevent accidental disconnection
- FEP cable covering resists chemicals and moisture
Environmental Performance
- Explosive atmosphere Ex i certified operation
- Wide temperature range from -40°C to +180°C
- IP68 protection for harsh environmental conditions
- 5 g vibration resistance for high-vibration areas
- 15 g shock survival for industrial impacts
Installation Requirements
- Requires IQS900 signal conditioner for operation
- Hand-tighten connectors until locked position
- Maintain cable bend radius for optimal performance
- Follow explosive area installation guidelines
- Ensure proper grounding in hazardous locations
Shipping & Warranty
- 12-month comprehensive manufacturer warranty
- FedEx, UPS, DHL express shipping available
- 3-5 business day delivery standard
- International shipping to most countries
Frequently Asked Questions
- What does Ex i certification mean?
- Ex i means intrinsically safe for explosive atmospheres. It prevents ignition of flammable gases or dusts.
- How accurate is the 9.5 meter cable length?
- The length has ±950 mm tolerance. This allows for installation variations in field applications.
- What is the advantage of FEP cable covering?
- FEP resists almost all chemicals and has low moisture permeability. It maintains flexibility in cold conditions.
- Can this system operate in wet conditions?
- Yes, the IP68 rating allows submersion in water. The transducer head is completely protected against water ingress.
- What maintenance does the system require?
- Regular inspection of cables and connectors is recommended. Check for physical damage during routine maintenance.
