Meggitt Vibro-Meter Proximity System with Flexible Hose
The 913-402-000-012/A2-E090-F1-G088 offers complete protection for explosive environments. This system includes a 9.0 meter cable and 8.8 meter flexible hose. The 913-402-000-012/A2-E090-F1-G088 provides maximum mechanical protection in harsh conditions.
Complete Product Configuration
- Core System: 913-402-000-012 Proximity Measuring
- Safety Rating: A2 – Explosive Atmosphere Ex i
- Electrical Cable: E090 – 9.0 meters length
- Mechanical Protection: F1 – Flexible Hose Included
- Hose Length: G088 – 8.8 meters protection
Detailed Specifications
- Total Cable Length: 9.0 meters ±900 mm
- Flexible Hose Length: 8.8 meters exact
- Normal Operation: -40°C to +180°C
- Emergency Temperature: Up to +220°C short-term
- System Weight: 0.22 kg complete unit
- Vibration Limit: 5 g peak (10-500 Hz)
- Shock Resistance: 15 g peak (11 ms)
- Weather Protection: IP68 rated transducer
- Cable Impedance: 70 Ω coaxial design
- Probe Diameter: 8 mm standard size
Enhanced Protection Features
- 8.8 meter stainless steel flexible hose
- Explosive atmosphere Ex i certification
- IP68 rating for complete environmental sealing
- Stainless steel AISI 316L construction
- Torlon probe tip for extreme wear resistance
- FEP cable covering resists all chemicals
- High-temperature epoxy encapsulation
- Self-locking coaxial connectors
Performance Characteristics
- Ex i certified for hazardous locations
- Flexible hose prevents cable damage
- Wide temperature operation range
- Excellent vibration and shock survival
- Chemical resistant FEP cable jacket
- Stainless steel hose for mechanical protection
System Requirements
- Requires IQS900 signal conditioner
- Hand-tighten connectors until lock
- Follow explosive area safety codes
- Install hose for maximum protection
- Maintain proper bend radii
Service Information
- 12-month manufacturer warranty
- FedEx, UPS, DHL express delivery
- 3-5 business day shipping
- Global shipping available
Common Questions
- What is the purpose of the flexible hose?
- The hose provides mechanical protection against impact and abrasion. It extends the cable life in tough environments.
- How does the hose length compare to cable length?
- The hose is 8.8 meters and cable is 9.0 meters. This allows for proper connection at both ends.
- Can the hose withstand high temperatures?
- Yes, the stainless steel hose handles the full temperature range. It protects the cable in hot areas.
- What maintenance does the hose require?
- Inspect regularly for damage or kinks. Ensure the hose connections remain secure during operation.
- Is the hose waterproof?
- The hose provides mechanical protection only. The IP68 rating comes from the transducer design itself.
