3636T Relay Output Module for Industrial Control Systems

3636T Relay Output Module Overview

The 3636T Relay Output Module provides reliable switching for industrial control systems. It features 32 independent relay points with advanced diagnostics. This module handles non-critical applications requiring robust performance.

Technical Specifications

• Model Number: 3636T
• Module Type: Non-triplicated Relay Output
• Number of Points: 32 independent points
• Voltage Range: 155V AC/DC maximum
• Current Load: 2A maximum per point
• Switching Power: 2000 VA, 150 watts resistive
• Point Isolation: 1500 VDC to 2500 VDC
• Fuses: 2.5A fast-acting (one per output)
• Contact Type: Normally Open (NO)
• Color Code: Silver Blue
• Diagnostic Indicators: Output Status, Module Status
• Status Lights: PASS, FAULT, ACTIVE
• Backplane Compatibility: Tricon System
• Required Accessory: External Termination Panel (ETP)

Installation Requirements

• Requires External Termination Panel (ETP)
• Cable interface to Tricon backplane
• Proper voltage and current ratings
• Adequate ventilation and spacing
• Qualified technician installation
• Regular maintenance recommended

Warranty & Shipping

• 12-month warranty
• Worldwide shipping via FedEx, UPS, DHL
• Fast delivery within 3-7 business days
• Quality tested before shipment
• Tracking information provided

Technical FAQs

• What does non-triplicated mean?

Non-triplicated means the 3636T uses single-channel processing for non-critical applications.

• How many relays does this module have?

It contains 32 individual relay points, each with normally open contacts.

• What is the maximum voltage rating?

The module supports up to 155 volts AC or DC maximum per point.

• Does it require additional hardware?

Yes, it requires an External Termination Panel (ETP) for proper installation.

• What diagnostic features are included?

It has loopback circuits, status indicators, and ongoing operational diagnostics.

Ordering Information

• Product in stock and ready to ship
• Complete documentation included
• Technical support available
• Competitive pricing
• Bulk order discounts available
