3500/94M-07-12-02 Bently Nevada Router Box VGA Display Module 3500 Monitoring System

System Overview Bently Nevada 3500/94M VGA Display

The Bently Nevada 3500/94M-07-12-02 is a router box version for the 3500 monitoring system. It comes with no display but includes a 20‑foot (6m) Display Router Box cable. Perfect for remote mounting situations. Use it with the 3500/22 TDI module for full data access. Built for harsh industrial environments.

Part number 3500/94M-07-12-02 includes multi approvals (CSA/ATEX/IECEx). Made in U.S.A.

Model Decoder Suffix Structure

• 3500/94M-07-12-02
  • 07 = Router box, no display included
  • 12 = Display Router Box cable 20 ft (6m)
  • 02 = Multi approvals CSA/ATEX/IECEx

Hardware Components

• Monitor Module – 241.3 x 24.4 x 241.8 mm, 0.73 kg. Fits 1 full‑height front slot.
• I/O Module – 241.3 x 24.4 x 99.1 mm, 0.34 kg. Fits 1 full‑height rear slot.
• Display Router Box
  • Power input 24 Vdc ±6% (22.5‑25.5 Vdc), 4.7 W max
  • VGA input and output for video
  • RS232 input and output for touch data
  • OK status LED for proper operation
• Included Cable – 20 ft (6m) Display Router Box cable (option 12)
• KVM Extender (optional) – mounts on shelf top, 12/5 Vdc input

Key Technical Data

• Power consumption 4.6 W max (monitor module)
• Display input VGA port analog RGB, sync
• Front port 24 Vdc out, VGA out, touch commands
• RS232 port for touch controller data
• LED indicators OK (module health), TX/RX (communication)
• Operating temperature -20°C to 65°C (module)
• Humidity 95% non‑condensing

System Requirements & Compatibility

• Requires 3500/22 TDI module (Transient Data Interface).
• Firmware minimum versions: 3500/94M 4.06 Rev C, 3500/22 Rev 1.71.
• Software: Rack Config Rev 5.6, Op Display Rev 2.21, Data Acquisition Rev 1.22.
• Compatible with all 3500 racks and standard 3500 power supplies.
• Works with any VGA monitor (sold separately)

Certifications & Compliance

• Multi approvals CSA, ATEX, IECEx (option 02)
• EMC EN 61000‑6‑2, EN 61000‑6‑4, Directive 2014/30/EU
• Safety CSA C22.2 61010‑1, UL EN 61010‑1, Directive 2014/35/EU
• RoHS Directive 2011/65/EU
• FCC Part 15 – device complies, no harmful interference
• KVM receiver Class I Div 2 for North America

Environmental Limits

• Module operating -20°C to 65°C, storage -40°C to 85°C
• Router box operating same as module
• KVM extender operating 0°C to 45°C
• Humidity tolerance 95% RH (module), 80% (KVM)

Package Contents

• 3500/94M monitor module (front slot)
• I/O module (rear slot)
• Display Router Box
• 20 ft (6m) Display Router Box cable
• Installation and firmware manuals

Warranty & Shipping

• Warranty 12 months against defects in materials and workmanship.
• Shipping partners FedEx, UPS, DHL – fast worldwide delivery.
• Tracking number sent within 24 hours.

Frequently Asked Questions (FAQ)

• What is the Display Router Box used for?It lets you place a VGA monitor far from the rack. Use it with the 20‑foot cable included. Great for control rooms.
• Can I use my own monitor with this module?Yes. Any standard VGA monitor works. The Router Box sends video and touch data over the cable.
• Is the Router Box approved for hazardous areas?Yes. Option 02 gives CSA/ATEX/IECEx approval. Safe for Zone 1 and Class I Div 2 locations.
• What happens if I need a longer cable than 20 ft?Contact us for custom lengths. Maximum cable run depends on signal quality. We recommend staying under 100 ft.
• Does this module work with the 15‑inch Advantech display?Yes. The Router Box connects to any VGA display, including the Advantech FPM‑8151. You order the display separately.

Selection & Experience Tips

• Choose this version if you already have a display or need hazardous area approval.
• For cold rooms, remember the Advantech display needs 0°C minimum. The Router Box itself works at -20°C.
• Always match firmware versions. Old TDI firmware may not work with new 3500/94M.
• The KVM extender is separate. Order it if you need long distance keyboard/mouse control.
• Need help selecting the right cable length? Contact our team.
