Product details
Ovweview
Bently Nevada 3500/94M-05-00-CN VGA Display Module offers a reliable 15″ industrial display for precise monitoring and control. Built for harsh conditions, it ensures stable performance in critical systems.
Key Features
- Brand: Bently Nevada
- Model: 3500/94M-05-00-CN
- Display: 15″ Advantech FPM-8151 LCD with LED backlight
- Mounting: 19″ rack mount, 1 full-height front slot
- Power: 12–24 Vdc, 4.6W max
- Inputs: VGA, RS232, high-speed network
- Outputs: VGA, 24 Vdc power, touch input
- Temp Range: -20°C to 65°C operating, -40°C to 85°C storage
- Humidity: 95% non-condensing
- Weight: 1.07 kg total
Certifications
- FCC Part 15 compliant
- EN 61000-6-2, EN 61000-6-4
- UL / CSA C22.2 61010-1
- RoHS 2011/65/EU
- Directive 2014/30/EU & 2014/35/EU
Suffix Breakdown
- 05 = 15″ display, 19″ rack mount
- 00 = No KVM or router cables
- CN = Country-specific approval
System Compatibility
- Requires 3500/22 TDI module
- Firmware: 3500/94M v4.06, 3500/22 v1.71
- Software: Rack Config v5.6, Op Display v2.21, Data Acquisition v1.22
Installation Guide
- Front module: 1 full-height front slot
- I/O module: 1 full-height rear slot
- Connect to 3500/22 TDI for data interface
- Use regulated 24 Vdc power supply
Packing List
- 3500/94M-05-00-CN Display Module
- I/O rear module
- 15″ Advantech FPM-8151 Display
- Connection and power cables
- Ships via FedEx / UPS / DHL
Environmental Notes
- IP65 front protection with Advantech display
- Use heated enclosure below 0°C
- KVM Receiver: Class I, Div 2 approved
- Transmitter requires safe area installation
FAQ
- Q: Is this module compatible with older 3500 racks?
- A: Yes, with 3500/22 TDI and correct firmware versions.
- Q: Can the display be replaced?
- A: Yes, use 15″ rack-mount models with RS232 touch support.
- Q: What environment is ideal for operation?
- A: Use within -20°C to 65°C, with stable DC power.
