3500/94M-02-00-01 Bently Nevada VGA Display — Industrial Rack Monitor

Bently Nevada 3500/94M VGA Display – Compact 10″ Rack System

• Model: 3500/94M-02-00-01
• Type: VGA Display Unit
• Manufacturer: Bently Nevada
• Condition: New & Original Factory Packaging
• Warranty: 12 Months

Main Features

• 3500/94M uses a 10″ Advantech LCD with LED backlight and resistive touch.
• Power use under 4.6 W ensures low energy draw.
• Accepts 24 V DC input (10–28 V DC range) with stable output.
• Front port supports power out, VGA signal out, and touch input.
• Easy 19″ rack mount setup with strong steel housing.

Performance & Electrical

• High-speed network for live data and machine values.
• RS232 I/O for touch controller communication.
• OK LED shows proper module function; TX/RX LED shows communication status.
• Voltage tolerance 10–28 V DC, operating current < 500 mA, inrush < 3.5 A @24 V.

Environmental Limits

• Operating temperature: -20°C to +65°C.
• Storage temperature: -40°C to +85°C.
• Humidity: up to 95% non-condensing.
• IP54 front protection; suitable for dusty or humid environments.
• Class I, Division 2 and ATEX/IECEx compliant.

Mechanical Details

• Display module: 241.3 × 24.4 × 241.8 mm, 0.73 kg.
• I/O module: 241.3 × 24.4 × 99.1 mm, 0.34 kg.
• Display screen: 389 × 249 × 48 mm, 4.0 kg shipping weight.
• Touch type: GFG resistive, diagonal 10.5 inches.
• Mount styles: face, rack, panel, or independent mount.

Compliance & Certification

• EMC: EN 61000-6-2, EN 61000-6-4 (Directive 2014/30/EU).
• Electrical Safety: UL EN 61010-1, CSA C22.2 61010-1 (Directive 2014/35/EU).
• RoHS Directive 2011/65/EU.
• FCC Part 15 compliant with interference protection.

System Compatibility

• Works with 3500/22 TDI Transient Data Interface module.
• Requires Firmware 4.06 Rev C or higher.
• Supports Rack Config 5.6, Op Display 2.21, Data Acquisition 1.22.

Logistics & Packaging

• Includes: VGA Display, I/O module, and power cable.
• Ships worldwide via FedEx, UPS, or DHL.
• Delivered in anti-static, shockproof packaging for safety.

Product Advantages

• Wide temperature range for harsh industrial environments.
• Compact design saves rack space and wiring time.
• Reliable Advantech touch screen with long service life.
• CSA/NRTL/C approval ensures safe field operation.

FAQ

• Q:How can I connect the 3500/94M to other modules?
  A:Use the RS232 and VGA ports with the 3500/22 TDI for full integration.
• Q:Can the screen run below -20°C?
  A:Below -20°C, use a heated enclosure to maintain visibility and protect the bezel.
• Q:What maintenance is recommended?
  A:Clean the touch screen gently and check LED indicators monthly for system health.
• Q:What’s the ideal power setup?
  A:Provide a stable 24 V DC power supply; avoid shared noisy lines.
• Q:How often should firmware be updated?
  A:Update yearly or when Bently releases new system firmware for the 3500 series.
