Product details
Product Overview
- Brand: :Bently Nevada
- Model: 3500/94M-01-00-00
- Series: 3500 Machinery Protection System
- Type: VGA Display Module
- Description: Industrial display for real-time system monitoring
- Provides clear system status, values, and alarms
- Supports rack-mounted monitoring systems
- Designed for harsh industrial environments
- Ensures stable and reliable visual diagnostics
Configuration Breakdown
- 3500/94M-AA-BB-CC
- ↳ AA: 01 = 10″ display, face mount
- ↳ BB: 00 = No KVM extender cables
- ↳ CC: 00 = No agency approvals
Technical Specifications
- Power Consumption: Max 4.6 W
- Input Signals: High-speed network data
- Output Signals: VGA analog RGB and sync
- Communication: RS232 touch interface
- Resolution: High clarity industrial display
- Temperature Range: -20°C to 65°C
- Storage Range: -40°C to 85°C
- Humidity: Up to 95% non-condensing
- Anti-interference: Strong EMC compliance
- Durability: Industrial hardened design
Physical Characteristics
- Module Size: 241.3 × 24.4 × 241.8 mm
- I/O Module Depth: 99.1 mm
- Total Weight: 1.07 kg
- Compact rack-mounted design
Installation Guide
- Install in one full-height front rack slot
- Attach I/O module in rear slot
- Connect VGA and power cables securely
- Ensure stable 24 Vdc power supply
- Use proper grounding for safety
Commissioning & Maintenance
- Quick startup with plug-and-play design
- LED indicators show system status
- Low maintenance required
- Easy troubleshooting via display interface
- Firmware updates supported
Compatibility
- Requires 3500/94M system integration
- Works with 3500/22 TDI module
- Supports system software packages
- Compatible with Advantech industrial displays
Certifications
- EMC: EN 61000-6-2, EN 61000-6-4
- Safety: UL, CSA standards
- Directive: 2014/30/EU, 2014/35/EU
- RoHS: 2011/65/EU compliant
Typical Applications
- Power plants monitoring systems
- Oil and gas equipment diagnostics
- Industrial automation control rooms
- Rotating machinery protection systems
- Process control visualization
Diagnostic Capabilities
- Real-time machine condition display
- Alarm and fault visualization
- Communication status monitoring
- System health indicators
Packing List
- 1 × VGA Display Module
- 1 × I/O Module
- 1 × User documentation
- Standard industrial packaging
Warranty & Shipping
- Warranty: 12 months
- Shipping: FedEx, UPS, DHL
- Fast global delivery available
FAQ
- Can this module work without TDI?
- No. It requires the 3500/22 TDI module.
- Is the display suitable for harsh environments?
- Yes. It supports wide temperature and high humidity.
- How to confirm compatibility?
- Check firmware and system version requirements.
- What is the typical failure sign?
- LED indicators show communication or power issues.
- How to choose the right display size?
- Select based on rack space and visibility needs.
- Is it easy to install?
- Yes. Standard rack installation simplifies setup.
