Product details
Bently Nevada 330980-70-00 NSv Proximitor Sensor
Product Overview
The 330980-70-00 is a NSv Proximitor Sensor with a 7.0-meter system length. It is made for use with non-contacting probes. Its slim shape fits tight spaces and panels. The sensor resists signal noise from nearby radio or electrical sources.
Main Technical Specs
- System Length: 7.0 meters (23.0 feet)
- Mount Type: Panel mount
- Housing: A380 aluminum
- Weight: 255 g (9 oz)
- Input: Works with 3300 NSv or RAM probe + extension cable
- Power Range: -17.5 Vdc to -26 Vdc (without barriers)
- With Barriers: -23 Vdc to -26 Vdc
- Max Current: 12 mA
- Output Resistance: 50 ohms
- Supply Sensitivity: Less than 2 mV per volt
Environmental Conditions
- Operating Temperature: -52°C to +100°C
- Storage Temperature: -52°C to +105°C
- Humidity: 100% condensing (not submersible)
Model and Suffix Code Tree
- 330980: NSv Proximitor Sensor
- 70: 7.0-meter length, panel mount
- 00: No approval required
Installation Guide
- Mount to panel using standard tools
- Quick wiring using SpringLoc terminals
- DIN rail mount also supported
Warranty
- Factory 12-month warranty
Shipping Options
- Worldwide fast delivery via FedEx, UPS, or DHL
