Product details
Overview
The Bently Nevada 330903-00-04-05-02-CN NSv Proximity Probe offers mid-length 40 mm case flexibility for versatile installations. Certified for regional compliance (-CN), it uses a standard cable with ClickLoc connectivity. This probe replaces legacy 3300 RAM models and ships factory-sealed with a 12-month warranty.
Model Decoder
- -00- Zero unthreaded length
- -04- 40 mm case
- -05- 0.5 m cable
- -02- ClickLoc + standard cable
- -CN Local safety certifications
Technical Specifications
- Part No.: 330903-00-04-05-02-CN
- Resistance: 4.0 Ω ±0.5 Ω @0.5m
- Cable Stats:
- Center wire: 0.220 Ω/m ±0.3%
- Shield: 0.066 Ω/m ±1%
- Capacitance: 69.9 pF/m ±1.8%
- Installation:
- M8x1 thread (12 mm depth)
- Bend radius: 25.4 mm
- Output: -1 Vdc (0.25mm) to -13 Vdc (1.75mm)
- Temp Range: -52°C to +177°C
Why Choose This Probe?
| ▶ Mid-Size Case | 40 mm balances space and depth needs |
| ▶ Regional Cert | Pre-approved for local regulations (-CN) |
| ▶ Rugged Build | PPS tip + 304 SST case |
| ▶ Pressure Seal | Viton O-ring (1.6 MPa rated) |
