Bently Nevada 330702-00-10-90-02-00 Proximity Probe
Product Summary
11mm industrial proximity probe for vibration monitoring. With 9m armored cable and ClickLoc connector. Works in extreme temperatures.
Product Code Explained
- 330702: 11mm Probe with 1/2-20 UNF thread & armor
- 00: Unthreaded length = 0.0 inches
- 10: Case length = 1.0 inch
- 90: Cable length = 9 meters
- 02: Miniature ClickLoc connector
- 00: No agency approvals needed
Key Specifications
- Temperature range: -52°C to +177°C
- Probe tip: Polyphenylene sulfide (PPS)
- Case material: AISI 304 stainless steel
- Cable type: 75Ω triaxial FEP-insulated
- Resistance: 8.5Ω ±1.1 (center to outer)
Installation Guide
- Max torque: 15.2 N•m (133 in•lb)
- Thread engagement: 0.75 inches max
- Min bend radius: 25.4 mm (1.0 in)
- Pressure seal: Viton O-ring
Environmental Ratings
- Extreme temperature operation
- Avoid below -34°C to prevent seal damage
- Hazardous area compatible
Package & Support
- Shipping weight: 0.17 kg
- 12-month warranty
- Global delivery: FedEx, UPS, DHL
FAQ
- Q: Minimum bend radius?
A: 25.4 mm (1.0 inch) - Q: Thread size?
A: 1/2-20 UNF thread - Q: Cable insulation material?
A: Fluoroethylene propylene (FEP) - Q: Pressure sealing?
A: Viton O-ring (not pressure-tested) - Q: Warranty start?
A: 12 months from delivery date
