330505-01-02-00 Bently Nevada Low Frequency Velocity Sensor

Bently Nevada 330505-01-02-00 Low Frequency Velocity Sensor

Technical Specifications

• Model: 330505
• Mounting Angle: 0 degrees ±10%
• Mounting Thread: 3/8-24 UNF-2B
• Output Signal: 20 mV/mm/s (508 mV/in/s) ±10%
• Frequency Range: 0.5 to 1000 Hz ±3 dB, 1 to 200 Hz ±0.9 dB
• Velocity Range: Up to 102 mm/s (4 in/s)
• Accuracy: ±3% of full range
• Bias Voltage: -12 ±1 VDC
• Max Cable Length: 305 m (1000 ft) without signal loss (with 3500/46M)
• Operating Temp: -40°C to +100°C
• Shock Resistance: 981 m/s² (100 g)
• Humidity: 100%, non-submerged
• Material: Stainless Steel 300 series
• Weight: Less than 375 g
• Connector: 2-pin MIL-C-5015, sealed
• Mounting Torque: 46 kg·cm (40 in-lb) max

Packaging Information

• New & Original in sealed factory box
• Includes sensor and connector
• Warranty: 12 Months factory warranty

Delivery Options

• FedEx
• UPS
• DHL

Model Number Breakdown (330505-01-02-00)

• 330505 – Low Frequency Velocity Sensor Series
• -01 – Mounting Angle: 0° ±10°
• -02 – Internal Thread: 3/8-24 UNF-2B
• -00 – No Mounting Adapter
