Bently Nevada 330191 Compact Proximity Probe
Experience precision monitoring with the 330191-40-75-05-00 short-length proximity probe. This 0.5-meter sensor features extended 7.5-inch case design for challenging installations. Perfect for space-constrained industrial applications.
Compact Design Features
- Short 0.5 meter (1.6 feet) cable length
- Extended 7.5-inch case for deep mounting
- 4.0-inch unthreaded section for flexible installation
- Rugged 8mm PPS tip construction
- Stainless steel body for corrosion resistance
- Full 12-month manufacturer warranty protection
Detailed Specifications
- Complete Part Number: 330191-40-75-05-00
- Cable Length: 0.5 meters / 1.6 feet
- Unthreaded Length: 4.0 inches
- Overall Case Length: 7.5 inches
- Power Requirements: -17.5 Vdc to -26 Vdc
- Maximum Current: 12 mA
- Probe Resistance: 7.45 ± 0.50 ohms
- Output Impedance: 50 ohms
- Temperature Range: -55°C to +232°C
- Cable Strength: 330N (75 lbf) pull resistance
- Mounting Thread: 3/8-24 UNF
- Thread Engagement: 0.563 inches maximum
- Connector Material: Gold-plated brass/beryllium copper
- Maximum Torque: 0.565 N•m (5 in•lbf)
Part Number Decoder
- 330191 → 3300 XL 8mm ETR Probe Base
- 40 → Unthreaded Length: 4.0 inches
- 75 → Case Length: 7.5 inches
- 05 → Cable Length: 0.5 meters
- 00 → No Agency Approvals Required
Installation Benefits
- Short cable ideal for tight spaces
- Long case reaches deep into equipment
- Unthreaded section allows flexible positioning
- TipLoc technology ensures secure tip bonding
- CableLoc design provides 330N pull strength
- Optional FluidLoc prevents fluid migration
- Gold connectors maintain signal integrity
- Viton O-ring seals against pressure differential
Shipping & Warranty
- Factory fresh in original sealed packaging
- Express shipping: FedEx, UPS, DHL available
- Quality assurance testing completed
- 12-month comprehensive warranty included
- Technical support always available
Technical Resources
- Complete product specification sheet
- Detailed installation instructions
- Application guidelines
- Compatibility information
- Maintenance recommendations
Access Complete Technical Documentation Here
Technical Support Questions
- What is the unthreaded section used for?
The 4.0-inch unthreaded area allows flexible mounting in various applications.
- How does the short cable benefit installations?
The 0.5-meter length is perfect for space-constrained locations.
- What is the maximum case length available?
This model features a 7.5-inch case for deep mounting requirements.
- Does it require special certifications?
No agency approvals are needed for this standard industrial version.
- What is the probe tip encapsulation?
Thick 8mm PPS plastic provides superior coil protection.
