Bently Nevada 330191-00-40-50-CN Long-Range Proximity Probe
This industrial 330191-00-40-50-CN proximity probe offers extended 5-meter cable capability. Designed for challenging industrial environments, it provides reliable vibration monitoring. The 8mm ETR construction ensures maximum durability and performance.
Product Identification & Specifications
- Manufacturer: Bently Nevada
- Complete Model: 330191-00-40-50-CN
- Product Type: 8mm ETR Proximity Probe
- Cable Length: 5.0 Meters (16.4 Feet)
- Voltage Range: -17.5 Vdc to -26 Vdc
- Output Resistance: 50 Ω Standard
- Probe Resistance: 8.73 ± 0.50 Ω
- Case Length: 4.0 Inches Total
- Temperature: -55°C to +232°C
- Thread Type: 3/8-24 UNF
- Weight: Approximately 1.6 kg
Part Number Configuration
- Full Code Breakdown:
- 330191 – 3300 XL 8mm Probe Base
- 00 – No Unthreaded Section
- 40 – 4.0 Inch Case Length
- 50 – 5.0 Meter Cable Length
- CN – Country Specific Approval
- Compatibility: 5 Meter Proximitor Sensor Only
- Construction: Without Armor Option
- Sealing: Viton O-Ring Standard
- Warranty Coverage: 12 Full Months
Enhanced Performance Features
- Extended 5-Meter Cable for Flexible Installation
- TipLoc Patented Molding Technology
- CableLoc Design with 330N Pull Strength
- Optional FluidLoc Cable Available
- Thicker 8mm Probe Tip for Impact Resistance
- Gold-Plated Connectors for Superior Contact
- Stainless Steel Case for Corrosion Protection
Electrical & Mechanical Properties
- Power Supply Range: -17.5 Vdc to -26 Vdc
- Maximum Current Draw: 12 mA
- Supply Sensitivity: < 2 mV per Volt Change
- Connector Torque Limit: 0.565 N•m
- Maximum Thread Engagement: 0.563 Inches
- Tensile Strength: 330 N at Case Connection
- Cable Type: 75Ω Triaxial FEP Insulated
Shipping & Package Contents
- Condition: Brand New & Factory Sealed
- Shipping Methods: FedEx, UPS, DHL Available
- Delivery: Worldwide Express Service
- Package: Industrial Protective Packaging
- Tracking: Provided for All Orders
- Lead Time: Usually Ships Within 24 Hours
Technical Documentation Access
- Complete Product Datasheet:
- Installation Manuals Available
- Application Notes Provided
- Technical Drawings Accessible
Expert Technical Questions
- What makes the 5-meter version special?
This version works only with 5-meter Proximitor sensors. It has specific calibration for longer cable runs.
- Can I use this probe in hazardous areas?
The CN option provides country-specific approvals. Check local regulations for hazardous area certification.
- How does cable length affect performance?
Longer cables may require system recalibration. The 5-meter version is pre-calibrated for its length.
- What maintenance is required?
Regular visual inspection and connector checks. Monitor for cable damage or connector corrosion.
- Is special tools needed for installation?
Basic mechanical tools are sufficient. Use proper torque wrench for connector installation.
Pricing & Ordering Details
- Product Code: 330191-00-40-50-CN
- Brand: Bently Nevada (Baker Hughes)
- Series: 3300 XL Vibration Monitoring
- Stock Status: Available for Immediate Dispatch
- Contact Email: sales@powergearx.com
- Technical Support: +86 18030005825
