330191-00-08-10-05 3300 XL Proximity Probe — Bently Nevada Industrial Monitoring

Bently Nevada 330191-00-08-10-05 Proximity Probe Overview

The 330191-00-08-10-05 from Bently Nevada 3300 XL series is built for stable vibration and position sensing. Its 8 mm probe tip ensures precise readings under extreme industrial stress. Each unit is factory packed, new, and includes a 12-month warranty.

Shipping available via FedEx, UPS, or DHL for worldwide delivery.

Highlights

• Durable 8 mm PPS probe tip for improved wear resistance and heat stability.
• Patented TipLoc and CableLoc bonding for secure mechanical connection.
• Strong tensile design — 330 N (75 lbf) between probe and cable.
• Compact 1.0 m total probe length — ideal for limited-space mounting.
• CSA, ATEX, and IECEx certified for global compliance.

Ordering Structure

• Base Model: 330191 — 3300 XL 8 mm ETR probe, 3/8-24 UNF thread, no armor.
• Unthreaded Length (00): 0.0 in.
• Case Length (08): 0.8 in.
• Total Length (10): 1.0 m (3.3 ft).
• Agency Approval (05): CSA / ATEX / IECEx certifications.

Technical Specifications

• Manufacturer: Bently Nevada
• Model: 330191-00-08-10-05
• Series: 3300 XL Proximity Probe
• Case Material: AISI 303/304 stainless steel
• Probe Tip Material: PPS (Polyphenylene Sulfide)
• Nominal Resistance: 7.59 ± 0.50 Ω (1.0 m)
• Voltage Range: -17.5 Vdc to -26 Vdc (12 mA max)
• Output Resistance: 50 Ω
• Supply Sensitivity: Less than 2 mV/V
• Tensile Strength: 330 N probe to lead / 270 N lead to connector
• Connector Torque: 0.565 N·m (5 in·lbf)
• Cable Type: 75 Ω triaxial (FEP or PFA insulation)
• Thread Engagement: 3/8-24 UNF, 0.563 in max
• Temperature Range: -55°C to +232°C (Probe only)

Performance Advantages

• Delivers stable signal output even with voltage variations.
• Improved pressure sealing using Viton® O-ring.
• FluidLoc option prevents fluid leakage through internal cable channels.
• Ideal for harsh process industries and turbine vibration monitoring.

Installation Tips

• Use 3/8-24 UNF thread and secure engagement at 0.563 inches max.
• Avoid cable bends near probe tip to reduce mechanical strain.
• Check connection torque — do not exceed 0.565 N·m.
• Use with matching Bently Nevada extension cables for accuracy.

Package Includes

• 1 × 330191-00-08-10-05 proximity probe (factory sealed).
• 1 × Installation guide and product datasheet.
• 1 × Accessory O-ring and protective cover.

Shipping & Warranty

• All shipments handled via FedEx, UPS, or DHL.
• 12-month factory warranty ensures long-term reliability and service support.

Professional FAQ

• Is this probe compatible with older 3300 series drivers?
  Yes, it supports 3300 series systems with the same connector type.
• Can this model operate in high-vibration zones?
  Yes, the PPS tip and stainless case withstand continuous vibration stress.
• Does it need an extension cable for 1-meter setup?
  No, one-meter probes connect directly to the monitoring system.
• What voltage should I supply during installation?
  Provide between -17.5 and -26 Vdc for full accuracy.
• Can I request armored cable protection?
  Yes, armor made from AISI 302/304 stainless steel is available.
