Product details
Bently Nevada 3300 Series 5mm Vibration Probe (Model 330173-00-06-10-02-CN)
5mm industrial sensor (330173-00-06-10-02-CN)with M8×1 thread for machinery health monitoring. Features a 1.0m FEP cable and 60mm stainless steel case (AISI 304). Operates in -35°C to +177°C environments with ±0.5Ω accuracy.
Key Model Features
| Code | Feature | Detail |
| 00 | Unthreaded Length | 0 mm |
| 06 | Case Length | 60 mm |
| 10 | Cable Length | 1.0 m (3.3 ft) |
| 02 | Connector | ClickLoc Mini-Coaxial |
| CN | Certification | Country-Specific |
Technical Specifications
- Power: -17.5Vdc to -26Vdc @12mA max
- Output: 50Ω ±0.5Ω resistance
- Material: PPS tip + AISI 304 steel case
- Temp Range: -35°C to +177°C
- Cable: 75Ω triaxial FEP (1.0m)
Installation Guide
- Max torque: 7.3 N·m (65 in·lb)
- Cable bend: ≥25.4mm
- Compatible with Bently Nevada 3300/3500 systems
Package Includes
- Vibration probe unit
- ClickLoc connector set
- Installation manual
Industrial Applications
Used in power turbines, compressor stations, and heavy machinery for vibration monitoring.
