Bently Nevada 330130-070-02-00 Extension Cable
Product Overview
This is a 7.0 meter extension cable designed for 3300 XL 8 mm Proximitor sensor systems. It includes a standard cable with connector protector and silicone tape for optional sealing. Made in the USA.
Technical Specifications
- Model: 330130-070-02-00
- Cable Length: 7.0 meters (22.9 feet)
- Cable Type: Standard cable with connector protector
- Weight (Standard): 0.204 kg
- Weight (Armored): 0.618 kg
- Capacitance: 69.9 pF/m
- Center Conductor Resistance (RCORE): 1.54 ± 0.23 Ω
- Outer Conductor Resistance (RJACKET): 0.46 ± 0.09 Ω
Electrical Performance
- Voltage Supply: -17.5 Vdc to -26 Vdc (no barriers), -23 Vdc to -26 Vdc (with barriers)
- Max Current: 12 mA
- Output Resistance: 50 Ω
- Supply Sensitivity: < 2 mV per volt change
- Linear Range: 0.25 mm to 2.3 mm (approx. -1 to -17 Vdc)
Installation Guide
- Use with 3300 XL 8 mm probes and Proximitor sensors
- Includes corrosion-resistant ClickLoc connectors
- Recommended wiring: 0.2 to 1.5 mm² (16 to 24 AWG)
- Max wiring length to monitor: 305 meters (1000 feet)
Package Contents & Delivery
- 1 Extension cable (7.0 meters)
- Silicone tape included
- Shipped via FedEx, UPS, or DHL
- 12-month warranty
Model Suffix Breakdown
- 330130: Extension Cable Series
- 070: 7.0 meters length
- 02: Standard cable with connector protector
- 00: No special approvals required
