Product details
Bently Nevada 3300 XL 8mm Proximity Probe
Monitor machine vibration accurately. This 330103-06-20-10-02-00 probe is reliable and cost-effective. It is perfect for general industrial applications.
Product Configuration Breakdown
- Bently Nevada 3300 XL 8mm Probe
- Model: 330103 (Base: 8mm, M10x1 thread, no armor)
- Suffix -06: Unthreaded Length = 60mm
- Suffix -20: Overall Case Length = 200mm
- Suffix -10: Total Cable Length = 1.0 meter
- Suffix -02: Connector = Miniature ClickLoc (Standard Cable)
- Suffix -00: Agency Approval = Standard (Not Required)
Core Technical Specifications
- Measurement & Electrical
- Linear Range: 0.25 mm to 2.3 mm (10 to 90 mils)
- Recommended Gap: Set to ~1.27 mm (50 mils) for -9 Vdc output.
- Probe Resistance (1.0m): 7.59 Ω ± 0.50.
- Max Field Wiring: 305 meters to monitor.
- Physical Build
- Case Material: AISI 303/304 Stainless Steel.
- Tip Material: Durable PPS (Polyphenylene Sulfide).
- Seal: Viton® O-ring for basic environmental protection.
- Thread: M10 x 1. Engage max 15 mm.
- Operating Environment
- Temperature Range: -52°C to +177°C (-62°F to +350°F).
- Humidity: Stable performance (<3% change) at 93% RH.
- Note: Avoid below -34°C to protect the seal.
Expert FAQs & Selection Guide
Understanding This Model’s Design
- Q: What does the “06” unthreaded length mean for installation?
- A: It provides a 60mm smooth shaft before the M10 thread begins. This gives flexibility for mounting in deep holes or using locking nuts.
- Q: This probe has “-00” for approvals. Can I use it in hazardous areas?
- A: No. The -00 suffix means it lacks intrinsic safety certifications. Use it only in safe, non-hazardous locations.
Cable & Compatibility Questions
- Q: What is the difference between “FluidLoc” and this “Standard” cable?
- A: This model (-02) has a standard PVC jacket. It is for dry or mildly oily areas. Choose FluidLoc (suffix -12) for wet or chemical exposure.
- Q: Is the ClickLoc connector easy to install in the field?
- A: Yes. The ClickLoc connector simply pushes and clicks into the proximitor. It needs no tools. This makes replacement fast and easy.
Purchasing & Support
- Q: Do you offer volume pricing for multiple units?
- A: Yes. Contact us directly for a quote on bulk orders. We provide competitive pricing for plant-wide maintenance projects.
Ordering, Shipping & Guarantee
- Fast Global Shipping: We dispatch worldwide via FedEx, UPS, and DHL.
- Reliability Promise: All products include a full 12-month warranty.
- Ready to Ship: This Bently Nevada 330103-06-20-10-02-00 is typically in stock.
Need a Different Configuration or Advice?
Our team can help you select the perfect sensor.
Reach out for technical support or custom quotes:
- Email: sales@powergearx.com
- WhatsApp: +86 18030005825
