3300 XL 8 mm Proximity Probe | 330140-08-15-11-05- Bently Nevada

Overview

The 330140-08-15-11-05 is a 330141 3300 XL 8 mm Probe with armor, proudly made in the U.S.A by Bently Nevada. This product showcases significant improvements over previous designs. Patented molding methods ensure a more robust connection between the probe tip and body. An optional FluidLoc cable can be selected to prevent oil and other liquids from leaking through the cable’s interior. Additionally, customers have the option to add a Certificate Of Origin (COO).

Technical Specification

• Brand: Bently Nevada
• Model: 330140-08-15-11-05
• Suffix Meanings:
  • “08” indicates an overall case length of 0.8 inches.
  • “15” represents a total length of 1.5 meters (4.9 feet).
  • “11” stands for a Miniature coaxial ClickLoc connector with a connector protector and a FluidLoc cable.
  • “05” means it has CSA, ATEX, and IECEx Approvals.
• Nominal Probe DC Resistance: For a 1.5 – meter probe, it is 7.73 ± 0.50 Ω.
• Incremental Scale Factor:
  • Standard 5 or 1 – meter System: 7.87 V/mm (200 mV/mil) ± 5% (including interchangeability error) when measured in increments of 0.25 mm (10 mils) over the 80 mil linear range from 0°C to +45°C (+32°F to +113°F).
  • Standard 9 – meter System: 7.87 V/mm (200 mV/mil) ± 6.5% (including interchangeability error) when measured in increments of 0.25 mm (10 mils) over the 80 mil linear range from 0°C to +45°C (+32°F to +113°F).
  • Extended Temperature Range for 5 and 9 – meter Systems: 7.87 V/mm (200 mV/mil) ± 6.5% (including interchangeability error) when measured in increments of 0.25 mm (10 mils) over the 80 mil linear range from 0°C to +45°C (+32°F to +113°F).

Contact Informatio

For any inquiries regarding this product, please contact sales@powergearx.com

For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
