3300 NSv – Bently Nevada Proximity Probes 330910-05-09-10-01-CN

Bently Nevada 330910-05-09-10-01-CN Proximity Probe

Core Functionality

The 330910-05-09-10-01-CN monitors industrial equipment vibrations with M10X1 threading. Operates in -52°C to +177°C. Features 90mm stainless steel case and 1.0m armored cable.

Model Suffix Decoding

• -05: 50mm unthreaded section
• -09: 90mm total case length
• -10: 1.0m FEP-insulated cable
• -01: ClickLoc connector with protector
• -CN: Local compliance certification

Technical Parameters

• Resistance: 4.2Ω ±0.5 (1m cable)
• Thread Engagement: 15mm minimum
• Bend Radius: >25.4mm (1.0in)
• Weight: 14-150g (0.5-5.3oz)

Certifications

• Meets Chinese GB/T 3836 standards
• RoHS compliant

Installation Guidelines

• Apply finger-tight torque (0.56N·m max)
• Maintain ≥15mm thread depth
• Avoid storage below -34°C

Typical Applications

• Coal-fired power plant turbines
• Petrochemical pipeline pumps
• Cement plant rotary kilns
