24V DC Input Module – Allen-Bradley 1746-ITV16 For SLC 500

Allen-Bradley 1746-ITV16 SLC 500 24V DC Input Module – High-Speed & Reliable

The 1746-ITV16 is a fast 24V DC input module. It is part of the Allen-Bradley SLC 500 series. This module works with high-speed devices like encoders and counters. It is perfect for conveyor systems and position control. It has sixteen sourcing inputs for easy connection. The module responds very quickly to signal changes.

Detailed Technical Specifications

• Brand: Allen-Bradley
• Model: 1746-ITV16
• Series: SLC 500
• Input Type: 24V DC Sourcing
• Number of Points: 16
• Voltage Range: 10-30V DC
• Nominal Current: 8 mA @ 24V DC
• On Delay: 0.3 ms (max)
• Off Delay: 0.5 ms (max)
• Backplane Current: 85 mA @ 5V DC
• Power Dissipation: 3.6 Watts
• Isolation: Optical coupling

Installation & Wiring

Install the 1746-ITV16 in any SLC 500 chassis slot. It uses a source wiring configuration. The removable terminal block makes wiring simple. No special tools are required for installation.

Quality & Support

This Allen-Bradley 1746-ITV16 module comes with a 12-month warranty. We ship worldwide via FedEx, UPS, and DHL. Our support team is ready to help with your automation projects.

Professional FAQs

• What is the difference between sourcing and sinking wiring?
  This module uses sourcing wiring. This means it provides power to the field device.
• Can I use this module with a 120V AC signal?
  No. The 1746-ITV16 is designed only for 10-30V DC signals.
• How fast can this module read input signals?
  It can read signals in less than 0.5 milliseconds. This is very fast.
• Do I need a special power supply for this module?
  No. It gets all needed power from the SLC 500 backplane.
• Is this module good for reading encoder pulses?
  Yes. Its high speed makes it perfect for encoders and counters.
