Space-Saving Power: Allen-Bradley PowerFlex 40P Drive (22D-E4P2H204)
The Allen-Bradley 22D-E4P2H204 delivers 3HP motor control in a compact design. Perfect for tight spaces needing reliable speed adjustment.
Technical Specifications
- Model: 22D-E4P2H204
- Power: 3 HP (2.2 kW)
- Voltage: 600V AC 3-phase
- Current: 4.2A
- Mounting: Plate (75% space saving)
- Temperature: 40°C standard (50°C with spacing)
- Communication: DeviceNet ready
- Safety: DriveGuard certified
Key Benefits
- Space Master: Zero stacking saves panel space
- Easy Setup: DIN rail or panel mounting
- Smart Control: External HMI programming
- Safe Operation: Certified safety solutions
- Network Ready: Single DeviceNet option
Installation Guide
- Mount horizontally or vertically
- Keep 25mm spacing for 50°C operation
- Use shielded cables for DeviceNet
Support & Shipping
- Warranty: 12 months
- Delivery: FedEx/UPS/DHL
- Included: Drive, mounting plate, reset button
Expert FAQs
Q: Maximum operating temperature?
A: 40°C standard, 50°C with proper spacing.
Q: Network connection options?
A: DeviceNet via single option module.
Q: Panel space savings?
A: 75% smaller than standard enclosures.
Q: Safety certifications?
A: DriveGuard certified for safe operation.
Q: Programming methods?
A: External HMI or PC tool via DSI.
