Product details
Overview
The Allen-Bradley 22D-B017H204 is a high-performance AC-powered adjustable frequency drive from the PowerFlex 40P series by Rockwell Automation. Designed for industrial applications, this drive helps regulate motor speed and torque by adjusting the frequency supplied to the motor. It features a plate-mount, open NEMA Type (IP20) enclosure, ensuring effective protection against dust and debris while maintaining a compact and reliable design.
This drive is ideal for applications requiring precise motor control, providing consistent performance even in demanding environments. It operates on 240 Volts AC, 3-phase power, and has a horsepower rating of 5 HP. The 22D-B017H204 also includes an integral keypad and LED display for easy configuration and monitoring.
Technical Specifications
- Manufacturer: Rockwell Automation
- Brand: Allen-Bradley
- Model Number: 22D-B017H204
- Part Type: PowerFlex 40P Adjustable Frequency Drive
- Phase: Three-Phase
- Frame Size: B (Plate Mount)
- Input Voltage: 240 Volts AC (208V)
- Amperage: 17.5 Amps
- Horsepower: 5 HP
- Enclosure: Open NEMA Type – Plate Mount (IP20)
- Filter: No CE-Compliant Filter
- Output Current: 17.5 Amps
- Max Ambient Temperature: 10°C to 50°C (14°F to 122°F)
- Dimensions:
- Height: 4.92 inches
- Width: 8.03 inches
- Depth: 3.84 inches
- Motor Protection: Electronic motor overload protection
- Installation: Panel Mount
- Control: Integral keypad and LED display
- Brake System: Standard brake system
FAQ
Q: Does the 22D-B017H204 require special installation?
A: Yes, this drive must be panel-mounted for proper installation.
Q: What is the maximum operating temperature?
A: The drive operates within a temperature range of 10°C to 50°C (14°F to 122°F).
Q: Can the drive be used with any motor?
A: The 22D-B017H204 is versatile and can work with a wide range of motors, thanks to its autotune feature.
Check official datasheet for more detailed information: PowerFlex 40P
