Allen-Bradley 22B-E012N104: Powerful 10HP Drive
High-performance VFD for industrial applications. 414-660V input. Space-saving design. Advanced motor control. Flexible communication options.
Technical Specifications
- Power Configuration
- Model: 22B-E012N104
- Input: 414-660V AC, 3-Phase
- Output: 10 HP (7.5 kW), 12A
- Frame: Size C
- Control Features
- Control Modes: V/Hz & Sensorless Vector
- Autotune: Motor adaptation
- PID: Built-in controller
- Frequency: 0-400 Hz
- Installation
- Mounting: Panel or DIN Rail
- Enclosure: IP20 (IP30 optional)
- Space Saving: Zero stacking
- Cooling: Natural convection
- Connectivity
- Built-in: RS-485
- Optional: Ethernet/IP, DeviceNet
- I/O: 7 digital, 3 analog inputs
- Display: 4-digit LED with keypad
Order & Support
- Warranty: 12-month coverage
- Shipping: FedEx, UPS, DHL worldwide
- Certifications: CE compliant
- Enclosure Options: IP20 standard, IP30 optional
Technical FAQs
- Q: What’s the voltage range?
A: Works from 414V to 660V AC - Q: Can I add network communication?
A: Yes, supports Ethernet/IP, DeviceNet and more - Q: Does it save panel space?
A: Yes, zero-stacking design minimizes space - Q: What control modes are included?
A: Both V/Hz and sensorless vector control - Q: Is PID control available?
A: Yes, built-in PID for standalone operation
Documentation Download
Get complete installation guide:
Package Includes: 22B-E012N104 Drive Unit, Keypad, Mounting Hardware.
