200355 Accelerometer – 200355-13-00-00 | Bently Nevada

Bently Nevada 200355-13-00-00 Vibration Sensor with Magnetic Base

Key Technical Specs

• Output Signal: 100 mV/g ±20%
• Range: ±50 g
• Frequency: 0.5 – 10,000 Hz
• Noise Level: 350 micro-g (1-10 kHz)
• Resonant Freq: 25,000 Hz
• Power: 18 – 28 VDC
• Bias Voltage: 8 – 12 VDC
• Current: 2 – 20 mA
• Settling Time: 2 sec
• Output Impedance: <150 ohms

Operating Conditions

• Temp Range: -54°C to +121°C
• Shock: 5000 g peak
• Humidity: 100% condensing
• Protection: IP68 waterproof
• Electrical Isolation: >108 ohms

Physical Info

• Mounting: Magnetic base
• Thread: 1/4-28 female
• Height: 4.24 cm (1.65 in)
• Weight: 0.051 kg
• Body: Stainless steel
• Sensor: Ceramic, shear
• Connector: 2-pin, top exit
• Hex Size: 1.8 cm (11/16 in)

How to Install

• Fix sensor with magnetic base
• Clean the surface first
• Connect cable to 2-pin top plug
• Check power and signal output

Model Breakdown

• 200355: Sensor series
  • 13: Magnetic base
  • 00: 100 mV/g output
  • 00: No approvals

Package Includes

• 1 x Sensor 200355-13-00-00
• 1 x Magnetic base
• 1 x Dust cover
