200155-16-05 – Low Frequency Trendmaster Pro Accelerometer

Bently Nevada 200155-16-05 Low Frequency Accelerometer

Product Summary

The 200155-16-05 accelerometer is ideal for fin-fan and slow shaft applications. It works with ProTIM low-frequency velocity channels for reliable vibration monitoring.

Key Technical Data

• Model: 200155-16-05
• Sensitivity (80 Hz): 10.2 mV/(m/s²) (100 mV/g)
• Measurement Range: ±196 m/s² (±20 g)
• Frequency Range: 1.5 to 10,000 Hz (90 to 600,000 cpm)
• Resonant Frequency: >20 kHz (>1200 kcpm)
• Amplitude Linearity: ±2% (1 to 10g peak)
• Transverse Sensitivity: ≤7%
• Settling Time: ≤2000 ms
• Excitation Voltage: 4.7 to 5.5 V DC
• Output Bias Voltage: +2.5 ± 0.23 V DC
• Current Consumption: <800 µA

Physical Details & Installation

• Dimensions: 17.5 mm hex x 45.7 mm height
• Weight: 58 g (2.0 oz)
• Mounting Thread: 3/8-24 female
• Mounting Torque: 2.7 to 6.8 N·m (2 to 5 ft·lb)
• Mounting Stud Option: 16 = 3/8-24 to 1/2-13 UNC, 3/4 inch hex stud
• Sensing Element: Ceramic Shear type
• Housing Material: 316L stainless steel
• Cure Time: 24 hours if adhesive applied

Model Suffix Explanation

• -16-05: Mounting stud option 16 with multiple approvals (CSA, ATEX, IECEx)

Package Includes

• Bently Nevada 200155-16-05 accelerometer
• Mounting stud (3/4 inch hex)
• No certificates or manuals included

Shipping & Warranty

• Ships via FedEx, UPS, DHL
• 12-month warranty included
• 24/7 customer and technical support available
