1771-ID16 AC/DC Input Module by Allen-Bradley | 120V

Allen-Bradley 1771-ID16 | Versatile 16-Channel AC/DC Input Module

The Allen-Bradley 1771-ID16 is a flexible input module for PLC-5 systems. It handles both AC and DC signals. This makes it ideal for various industrial applications. You can use it with many field devices like switches and sensors.

Detailed Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1771-ID16
• Input Type: 16-point AC/DC Input
• AC Voltage Range: 77-138 VAC
• DC Voltage Range: 105-138 VDC
• Backplane Current: 75 mA
• AC Off-State Current: 4.0 mA (max)
• DC Off-State Current: 1.8 mA (max)
• AC Response (ON): 1 ms
• DC Response (ON): 1 ms
• AC Response (OFF): 9 or 18 ms
• DC Response (OFF): 9 ms
• Wiring Arm: 1771-WN
• Weight: 0.9 lbs (0.4 kg)
• Dimensions: 3.5 x 6.5 x 2.0 in

Compatibility Information

• Works with 1771-A1B or 1771-A4B chassis (and newer)
• Perfect for multi-phase isolated circuit uses
• Connects to float switches, limit switches, pushbuttons

Shipping & Warranty Details

• Includes: 1 x 1771-ID16 Module, 1 x 1771-WN Wiring Arm
• Shipping: FedEx, UPS, or DHL
• Warranty: 12 months

Frequently Asked Questions

• What is the main advantage of this module?
  It accepts both AC and DC signals without needing extra parts.
• Can I use it with any PLC-5 chassis?
  It needs a 1771-A1B or 1771-A4B chassis or a newer model.
• How does the filtering help my system?
  It stops false signals from electrical noise and switch bouncing.
• What is the power consumption of this card?
  It uses 75 milliamps of backplane current.
• Is the wiring arm reusable?
  Yes, you can use it again when you change a module.
