1769-L16ER-BB1B CompactLogix PAC with Ethernet/IP 32 Tasks

Allen-Bradley 1769-L16ER-BB1B CompactLogix Controller

The 1769-L16ER-BB1B is a powerful and flexible programmable automation controller. It is part of the 5370 L1 CompactLogix series by Rockwell Automation. This controller is perfect for small to medium automation applications. It offers built-in I/O and strong communication features.

Detailed Technical Specifications

• Brand & Model: Allen-Bradley 1769-L16ER-BB1B
• Memory: 384 KB user memory
• SD Card: Includes 1 GB card for storage (supports up to 2 GB)
• Communication Ports: 1x USB port, 2x Ethernet/IP ports
• Embedded I/O: 24V DC (16 Inputs + 16 Outputs)
• Max Expansion: 6x 1734 Point I/O modules
• Tasks & Programs: Supports 32 tasks with 100 programs per task
• Power Consumption: 1A @ 5V DC, 11.5W power dissipation
• Wire Size: 12-30 AWG (solid or stranded copper)
• Shipping: 3 lbs, 11x8x6 inches (via FedEx, UPS, DHL)
• Warranty: 12 months

FAQ

• What is the maximum number of I/O modules I can add?
  You can connect up to six 1734 Point I/O modules.
• Does this controller need a battery to save memory?
  No, it uses a special internal storage system instead.
• What types of network topologies does it support?
  It works with star, linear, and Device Level Ring (DLR) networks.
• Can I use different programming languages in one project?
  Yes, you can mix Ladder, Structured Text, Function Block, and SFC.
• What is the operating voltage for the built-in I/O?
  The embedded inputs and outputs use 24V DC.
