Allen-Bradley 1769-IA16: 16-Channel AC Input Module
The Allen-Bradley 1769-IA16 offers sixteen AC input channels for industrial automation. This compact module works with CompactLogix and MicroLogix 1500 systems. It handles 100-120V AC signals from field devices like switches and sensors.
Product Highlights
- 16 isolated AC input channels for versatile connectivity
- Wide voltage range from 79 to 132V AC operation
- Removable terminal block for easy wiring and maintenance
- Compact design saves panel space
- LED status indicators for each channel
- DIN rail or panel mounting options
- 12-month warranty for guaranteed performance
Technical Specifications
- Brand & Model: Allen-Bradley 1769-IA16
- Input Channels: 16 AC inputs
- Voltage Range: 79-132V AC operating
- Frequency Range: 47-63 Hz
- On-State Current: 5mA min @ 74V AC
- Off-State Current: 2.5mA max
- Input Delay: 20ms On/Off
- Power Consumption: 3.3W max
- Backplane Current: 115mA @ 5.1V DC
- Wire Size: 14-22 AWG
- Operating Temperature: 0° to 60°C (32° to 140°F)
- Isolation Voltage: 250V AC continuous
Package Includes
- 1769-IA16 AC Input Module
- Removable terminal block
- Installation documentation
- Shipping via FedEx, UPS, or DHL
Common Questions
- What devices connect to this module?
Switches, sensors, push buttons, and other AC field devices - Can it handle higher voltages?
No, maximum voltage is 132V AC - How many modules can I connect?
Up to 8 modules from the power supply - What’s the response time?
20 milliseconds for both on and off states - Is electrical isolation provided?
Yes, 250V AC continuous isolation
