Allen-Bradley 1762-L24AWAR MicroLogix 1200 Controller

The Allen-Bradley 1762-L24AWAR is a compact and versatile programmable logic controller designed for industrial applications. It offers reliable performance with 14 AC inputs and 10 relay outputs, supporting both sinking and sourcing configurations. Its robust design and wide operating voltage make it suitable for various automation environments.

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1762-L24AWAR (MicroLogix 1200 Series)
• Input Voltage: 120–240V AC
• Inputs: 14 points, 120V AC
• Outputs: 10 relay outputs
• On-State Voltage: 79–132V AC
• Off-State Voltage: 0–20V AC
• Operating Frequency: 47–63 Hz
• Leakage Current: 2.5 mA max
• Inrush Current: 250 mA at 120V AC
• Isolation Ratings: Multiple isolation zones including input/output to backplane

Installation and Connectivity

• The unit measures 3.5 x 4.33 x 3.43 inches for easy panel mounting.
• Use the integrated RS-232 port for HMIs or network communication.
• This controller can respond to messages but cannot initiate communications.

Packaging Information

• The product ships with the 1762-L24AWAR controller unit.
• We use FedEx, UPS, or DHL for fast and reliable delivery.

FAQ

• What type of outputs does the 1762-L24AWAR have?
  It has 10 relay outputs for maximum flexibility.
• What communications does it support?
  It supports DH Full-Duplex for network connectivity via its RS-232 port.
• What is the input voltage range?
  It operates on 120–240V AC input power.
