1756-OF8IK ControlLogix Analog Output | 8-Channel 16-Bit

Allen-Bradley 1756-OF8IK ControlLogix Isolated Analog Output Module: Precision Industrial Control Solution

Technical Specifications

• Brand: Allen-Bradley | Model: 1756-OF8IK | Series: ControlLogix
• Output Type: 8 isolated current/voltage channels
• Resolution: 16-bit precision
• Current Range: 0-20mA or 4-20mA
• Voltage Range: -10V to +10V
• Load Capacity: Up to 1000 Ohms (current mode)
• Isolation: 50V continuous protection
• Power: 6.5W dissipation | 400mA @ 24V DC

Installation & Compatibility

• Terminal Blocks: 1756-TBCH, 1756-TBS6H, 1756-TBNH, 1756-TBSH
• Wire Size: 14-22 AWG shielded copper (90°C+ rated)
• Mounting: ControlLogix chassis compatible

Protection & Diagnostics

• Real-time fault detection: Short-circuit/open-circuit alerts
• Overvoltage Protection: -30V to +30V range
• Environmental Rating: Conformal coated for moisture/dust resistance

Warranty & Delivery

• 12-month warranty
• Global Shipping: FedEx, UPS, DHL options
• Package Includes: 1756-OF8IK module

Frequently Asked Questions

• Q: Is channel-to-channel isolation provided?
  A: Yes, all 8 channels are individually isolated.
• Q: What wire type is recommended?
  A: Use 14-22 AWG shielded copper wire (90°C+ rated).
• Q: Does it support 4-20mA sinking?
  A: Yes, with 0-1000 Ohm load capacity.
