1756-OA16IK ControlLogix – 16-Channel Isolated AC Output

Allen-Bradley 1756-OA16IK Isolated Output Module – Reliable AC Power Control

Industrial-Grade AC Output Solution

The Allen-Bradley 1756-OA16IK delivers 16 isolated AC outputs (74-265V) for precise power control in industrial automation systems.

Technical Specifications

• Brand: Allen-Bradley
• Model: 1756-OA16IK
• Series: ControlLogix
• Type: Isolated AC output module
• Voltage Range: 74-265V AC
• Current Rating: 2A/point (30°C), 5A/module
• Power Dissipation: 5.5W max
• Backplane Power: 300mA @5V, 3mA @24V
• Terminal Blocks: 1756-TBCH, 1756-TBS6H

Why Choose This Module?

• Superior isolation (50V continuous) for safety
• Compact design fits standard ControlLogix chassis
• Energy efficient with low power consumption
• Easy to install and replace with removable terminals

Download Full Specifications

Get complete details in our ControlLogix I/O Modules Specifications PDF.

Shipping & Warranty

• Fast worldwide shipping: FedEx, UPS, DHL
• 12-month manufacturer warranty

FAQ

• Q: What’s the maximum ambient temperature?
  A: Rated for 60°C operation (derated current).
• Q: Can I use this for DC loads?
  A: No, AC only (74-265V).
• Q: Are the outputs optically isolated?
  A: Yes, fully isolated channels.
• Q: What chassis is compatible?
  A: All standard ControlLogix 1756 chassis.
• Q: Is surge protection included?
  A: No, requires external protection for inductive loads.

Order Now

Upgrade your control system with the Allen-Bradley 1756-OA16IK – precise, isolated AC power control for industrial applications!
