1756-OA16I Isolated Output Module | 16-Ch AC | ControlLogix

Allen Bradley 1756-OA16I ControlLogix Output Module – High-Power AC Control

Industrial Power Features

• 16 individually isolated outputs – no cross-channel interference
• Wide voltage range: 74-265V AC (47-63Hz)
• High current capacity: 2A per point @30°C
• Module total: 5A @30°C (4A @60°C)

Precision Switching

• Response Time: 9.3ms @60Hz (ON/OFF)
• Ultra-low leakage: <3mA per point
• Surge protection: 20A inrush handling
• Configurable fault states per channel

Rugged Performance

• Operating temp: 0-60°C (32-140°F)
• Vibration resistance: 5g @10-500Hz
• 30g operational shock rating
• Humidity range: 5-95% non-condensing

Smart Control Capabilities

• Hot-swappable with 1756-TBCH/TBS6H terminals
• Per-point fault mode configuration
• Program mode state selection
• LED status indicators per channel

Technical Specifications

• Backplane Power: 300mA @5.1V
• Power Dissipation: 5.5W max @60°C
• Isolation Voltage: 250V continuous
• Minimum Load: 10mA per point

Warranty & Logistics

• 12-month performance warranty
• Global shipping: FedEx | UPS | DHL

Module Comparison

• Vs 1756-IM16I: Output vs Input | Higher voltage range
• Vs 1756-IB16I: AC vs DC | Isolated outputs

Installation Resources

Download Full Wiring Guide ↗
Complete specifications and configuration details

Expert FAQs

• Q: Minimum load requirement?
  A: 10mA per point to maintain operation
• Q: Replace without system shutdown?
  A: Yes – hot-swappable design
• Q: Compatible with 120V and 240V systems?
  A: Yes – works from 74-265V AC
• Q: LED status when flashing?
  A: Indicates configuration mode active
• Q: Maximum ambient temperature?
  A: 60°C (140°F) with derated current

Package Contents

• 1756-OA16I output module
• Installation documentation
