1756-IA16 ControlLogix AC Input Module | 16-Channel 120V

Allen-Bradley 1756-IA16: 16-Channel AC Input Module for Harsh Industrial Environments

Technical Specifications

• Model: 1756-IA16 | Series: ControlLogix
• Input Type: AC Digital | Brand: Allen-Bradley
• Voltage Range: 74-132V AC (47-63Hz)
• Current Draw: 5-13mA (operating range)
• Response Time: 8-18ms (configurable)
• Groups: 2 groups of 8 channels
• Power: 5.8W max dissipation
• Terminal Blocks: 1756-TBNH/TBSH

Why Professionals Choose This

• ✅ 40% wider voltage range than standard modules
• 📊 Dual-filter timing options (9ms/18ms)
• 🏭 Handles dirty power conditions
• 🔧 Tool-free terminal replacement
• ⏱️ Fast 200µs cyclic update

Simple Installation

• 1. Slide into any ControlLogix chassis slot
• 2. Attach 20-pin terminal block
• 3. Connect AC input devices
• 4. Configure in Studio 5000

Reliability Guaranteed

• 📦 Fast global shipping: FedEx/UPS/DHL
• 🔒 12-month warranty
• 🧊 Industrial-grade packaging
• 🔄 30-day return policy

Expert FAQs

• Q: Minimum voltage for ON state?
  A: 74V AC with 5mA current
• Q: Works with 50Hz power?
  A: Yes – 47-63Hz range supported
• Q: Hot-swappable?
  A: Yes in compatible systems
• Q: Group isolation voltage?
  A: 250V between input groups
• Q: Maximum wire length?
  A: 100m (328ft) shielded cable

Get Complete Documentation

Download full installation guide:
1756-IA16 Technical Manual (PDF)
