170ADO35000 Discrete Output Module Modicon Momentum

Overview

The Schneider Electric Modicon Momentum 170ADO35000 is a versatile 32-channel discrete output base designed for the Modicon Momentum automation platform. This module utilizes solid-state switching technology for high reliability and long service life, offering excellent control for automation systems that require precise output management. It operates at a 24 V DC voltage level and supports a current of up to 0.5 A per channel, making it suitable for a wide range of industrial applications.

Technical Specifications:

• Brand: Schneider Electric
• Model: Modicon Momentum 170ADO35000
• Product Type: Discrete Output Base DC
• Discrete Output Type: Solid State Switch
• Nominal Voltage: 24 V DC
• Output Current: 0.5 A per channel, 8 A per group, up to 16 A per module
• Maximum Leakage Current: 1 mA at 24 V DC
• Surge Current: 5 A for 1 ms
• Response Time: 0.1 ms from state 0 to state 1, and vice versa
• Maximum Voltage Drop: <0.5 V at 0.5 A in state 1
• Short-Circuit Protection: Electronically protected outputs
• Current Consumption: 250 mA at 24 V DC
• Power Dissipation: Typical: 6 W, Maximum: 7.5 W
• Channel Isolation: 500 V AC
• Operating Temperature Range: 32°F to 140°F (0°C to 60°C)
• Storage Temperature Range: -40°F to 185°F (-40°C to 85°C)
• Humidity Resistance: Up to 95% RH without condensation
• Altitude: Up to 16,404.2 ft (5000 m)
• Marking: CE

For more detailed information, please check official datasheet: 170ADO35000 Discrete Output Module Modicon Momentum
