140CPS11100 AC Power Supply – Schneider Electric Quantum

Schneider Electric 140CPS11100 – Reliable Quantum Power Supply

The 140CPS11100 power supply module delivers stable 5.1V DC power for Modicon Quantum systems. It operates on 120-230V AC input and provides reliable performance in industrial environments.

Technical Specifications

• Brand: Schneider Electric
• Model: 140CPS11100
• Product Series: Modicon Quantum
• Type: Standalone Power Supply Module
• Input Voltage: 120-230V AC (100-276V AC range)
• Input Frequency: 47-63 Hz
• Output Voltage: 5.1V DC ±1%
• Output Current: 3A maximum
• Rated Power: 50 VA
• Efficiency: >85% at full load
• Ripple & Noise: <50 mV peak-to-peak
• Inrush Current: 10A at 230V, 20A at 115V
• Fuse Rating: 1.5A slow-blow
• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Safety Standards: UL 508, CSA C22.2 No 142
• Certifications: cUL, FM Class 1 Division 2
• Warranty: 12 months

Protection & Safety

• Overvoltage protection
• Overload protection
• Short circuit protection
• 4kV contact/8kV air ESD protection
• Electromagnetic field resistance (10 V/m)

Package Contents

• 1x 140CPS11100 Power Supply Module
• Installation documentation

Shipping Information

• Package Dimensions: 12.28″ × 6.42″ × 1.77″
• Package Weight: 23.5 oz (665 g)
• Shipping Methods: FedEx, UPS, DHL
• Delivery Time: 2-5 business days

Common Questions

• What input voltage does this power supply accept?
  It accepts 100-276V AC, making it suitable for worldwide use.
• What is the output rating?
  It provides 5.1V DC at up to 3A for Quantum system components.
• Does it have protection features?
  Yes, it includes overvoltage, overload, and short circuit protection.
• What certifications does this module have?
  It is cUL listed and FM Class 1 Division 2 certified for hazardous locations.
• Can it operate in extreme temperatures?
  Yes, it operates from 0°C to 60°C and stores from -40°C to 85°C.
